Compare SMART Board Pro Displays for Business
Models and specifications may vary by region. Please contact your local representative for details.
Download a printer-friendly PDF version of this table.
 |
 |
 |
 |
|---|
| Software | GX (V3) series | MX (V4) Pro series | 6000S (V3) Pro series | QX Pro series |
|---|---|---|---|---|
| SMART Meeting Pro® Room license | Optional | Included | Included | Included |
| SMART Meeting Pro Personal license (×10) | Optional | Included | Included | Included |
| SMART TeamWorks™ Room license | Optional | Optional | Optional | Optional |
| SMART Product Drivers and SMART Ink® | Included | Included | Included | Included |
| SMART Remote Management | Optional | Subscription for the length of the warranty | Subscription for the length of the warranty | Subscription for the length of the warranty |
| Embedded features | Digital whiteboard Web browser Screen sharing Input select File manager Overlay Split screen Picture-in-picture (PIP) with touch pass-through Interactive widgets App library |
Digital whiteboard Web browser Screen sharing Personalized home screen and settings Input select with live input preview Split screen Interactive widgets Templates, graphic organizers, and manipulatives File and app libraries Google Drive™ and OneDrive™ access |
Digital whiteboard Web browser Screen sharing Personalized home screen and settings Input select with live input preview Split screen Interactive widgets Templates, graphic organizers, and manipulatives File and app libraries Environmental sensors dashboard Tool Explorer™ Image Editor Google Drive and OneDrive access |
Digital whiteboard Web browser Screen sharing Personalized home screen and settings Input select with live input preview Split screen Interactive widgets Templates, graphic organizers, and manipulatives File and app libraries Environmental sensors dashboard Google Drive and OneDrive access |
| Display | GX (V3) series | MX (V4) Pro series | 6000S (V3) Pro series | QX Pro series |
| Screen sizes (diagonal) | 65" | 75" | 86" | 55" | 65" | 75" | 86" | 65" | 75" | 86" | 65" | 75" | 86" |
| Resolution | 4K UHD (3840 × 2160) | 4K UHD (3840 × 2160) | 4K UHD (3840 × 2160) | 4K UHD (3840 × 2160) |
| Refresh rate | 60 Hz | 60 Hz | 60 Hz | 60 Hz |
| Lifespan | ≥ 50,000 hours | ≥ 50,000 hours | ≥ 50,000 hours | ≥ 50,000 hours |
| LCD quality | Grade A | Grade A | Grade A | Grade A |
| Brightness1 | 400 cd/m² | 55": 300 cd/m² 65", 75", 86": 400 cd/m² |
350 cd/m² | 490 cd/m² |
| Display response time | ≤ 8 ms | ≤ 8 ms | ≤ 8 ms | ≤ 8 ms |
| Glass | Full heat-tempered | Anti-glare | Bonded | 55": Full heat-tempered | Anti-glare 65", 75", 86": Full heat-tempered | Anti-glare | Bonded |
Full heat-tempered | Anti-glare | Optically bonded | Anti-glare | Anti-fingerprint | Heat-tempered |
| Sensors | Ambient light | Infrared | Ambient light | Infrared | Proximity | Ambient light | Infrared | Room temperature | Humidity | Proximity | Ambient light | Infrared | Room temperature | Humidity | Volatile organic compound (VOC) | Particulate Matter (PM2.5)2 |
| Speakers | 2 integrated 20 W speakers | 55": 2 integrated 15 W speakers 65", 75", 86": 2 integrated 20 W speakers |
2 integrated 20 W speakers | Integrated soundbar featuring two 20 W speakers and a 15 W subwoofer |
| Microphone | N/A | Integrated linear six-microphone array with support for onboard acoustic echo cancellation | Integrated linear four-microphone array | Integrated linear eight-microphone array with visual mute status indicator and support for onboard acoustic echo cancellation |
| NFC sign in to a SMART Account | ||||
| Convenience buttons | Power | Home | Volume | Freeze frame | Power | Home | Volume | Input select | Screen shade | Freeze frame | Power | Home | Volume | Screen shade | Freeze frame | Power | Home | Volume | Microphone mute | Freeze frame |
| 1Brightness of individual displays can vary. 2The display’s environmental sensors are not life safety rated sensors: they provide general information only. |
||||
| Touch and interaction | GX (V3) series | MX (V4) Pro series | 6000S (V3) Pro series | QX Pro series |
| Touch technology | Advanced infrared | HyPr Touch™ with Advanced IR | HyPr Touch with InGlass™ | HyPr Touch with Advanced IR |
| Frame rate | ≥ 125 Hz | ≥ 200 Hz | ≥ 150 Hz | ≥ 300 Hz |
| Touch response time | ≤ 8 ms | ≤ 5 ms | ≤ 9 ms | ≤ 4 ms |
| Accuracy | 1 mm | 1 mm | 1 mm | 1 mm |
| Minimum object size | 2 mm | 2 mm | 2 mm | 2 mm |
| Continuous touch points (fully differentiated) | Up to 40 touch points (OS dependent) | Up to 20 touch points (OS dependent) | Up to 20 touch points (OS dependent) | Up to 40 touch points (OS dependent) |
| Interaction types | Pens | Touch | Gesture | Palm erase | Pens | Touch | Gesture | Palm erase | Pens | Touch | Gesture | Erase | Fine erase | Highlighter | Tool Explorer tools | Pens | Touch | Gesture | Erase | Fine erase | Highlighter | Tool Explorer tools |
| Eraser, pen, and touch differentiation (simultaneous tool differentiation) | 3 | |||
| Continuous pen, touch, and erase (continuously write, move, and gesture and erase simultaneously) | 3 | |||
| Eraser types | Palm erase | Palm erase | Palm erase | Fine erase | Eraser blocks | Palm erase | Fine erase | Eraser blocks |
| Azimuth erasing | Not supported | Not supported | Eraser blocks | Eraser blocks |
| Palm rejection | Non-writing hand in Android™ whiteboard | Not supported | Writing and non-writing hand | Writing and non-writing hand |
| Object recognition | 4 | |||
| Pressure-sensitive ink | ||||
| Automatic pen color recognition | ||||
| Unique Pen ID support | 2: Windows® and macOS, when using a finger to write or draw | 2: Windows and macOS, when using a finger to write or draw | Unlimited (available: 6 pens and dual‑color highlighter) | Unlimited |
| Tools included | Pens (×2) | Pens (×2) | Pens with unique IDs and fine erasers (×2) Erasers with angle of orientation (×2) |
Pens with unique IDs and fine erasers (×2) Erasers with angle of orientation (×2) |
| Pen type | Battery-less pen | Battery-less pen | Battery-less pen with fine eraser | Hybrid internally powered pen with fine eraser |
| Tool holders | Magnetic | Frame‑mounted | Magnetic | Frame‑mounted | Intelligent | Magnetic | Frame‑mounted | Intelligent | Magnetic | Frame‑mounted |
| Additional pen colors (sold separately) | N/A | N/A | 4 color pen set: blue, green, purple, and orange (with holder) Dual-color highlighter Magic Pen |
4 color pen set: blue, green, purple, and orange (with holder) Dual-color highlighter Magic Pen Multi-tool stylus (coming 2024) |
| 3A connected computer with SMART Product Drivers installed is required. Only supported in SMART Notebook and SMART Ink. 4When connected to a computer with SMART Product Drivers installed |
||||
| Embedded Android OS | GX (V3) series | MX (V4) Pro series | 6000S (V3) Pro series | QX Pro series |
| Operating system | Android version 11.0 (upgradable to Android 13.0)4 | Android version 11.0 | Android version 11.0 | Android version 11.0 |
| CPU | Quad-core | Quad-core | Quad-core |
|
| Memory | 8 GB DDR4 | 8 GB DDR4 | 6 GB DDR | 8 GB DDR4 |
| OS architecture |
32-bit (Android 11) 64-bit (Android 13) |
64-bit | 64-bit | 64-bit |
| Storage | 64 GB | 32 GB (up to 544 GB) | 32 GB (up to 544 GB) | 32 GB (up to 544 GB) |
| User interface | 4K UHD (3840 × 2160) | 1920 × 1080, scaler up to 2K | 1920 × 1080, scaler up to 2K | 1920 × 1080, scaler up to 2K |
| Updates | Over‑the‑air (OTA) | Automatic OTA | Automatic OTA | Automatic over‑the‑air (OTA) |
| 5Update available in 2024 using a USB drive (not available OTA). | ||||
| Network connectivity | GX (V3) series | MX (V4) Pro series | 6000S (V3) Pro series | QX Pro series |
| Wired | RJ45 (×2) 1000baseT | RJ45 (×2) 1000baseT | RJ45 (×2) 1000baseT | RJ45 (×2) 1000baseT |
| Wi-Fi | IEEE 802.11ax (Wi-Fi 6) supporting WEP, WPA, WPA2, WPA3 PSK, and 802.1X EAP authentication protocols Wi-Fi access point |
IEEE 802.11ax (Wi-Fi 6) supporting WEP, WPA, WPA2, PSK, WPA3, and 802.1X EAP authentication protocols | IEEE 802.11ac (Wi-Fi 5) supporting WEP, WPA, WPA2 PSK, and 802.1X EAP authentication protocols | IEEE 802.11ax (Wi-Fi 6) supporting WEP, WPA, WPA2, PSK, WPA3, and 802.1X EAP authentication protocols |
| Bluetooth® | 5.0 dual mode | 5.2 dual mode | 5.0 dual mode | 5.2 dual mode |
| Radio and Bluetooth restrictions? Learn more | ||||
| Inputs | GX (V3) series | MX (V4) Pro series | 6000S (V3) Pro series | QX Pro series |
| OPS PC accessory slot | ||||
| microSD slot | ||||
| HDMI® |
(×3) HDMI 2.0 with HDCP 1.4 and HDCP 2.2 support |
(×3) HDMI 2.1 4K @ 60Hz with HDCP 1.4 and HDCP 2.3 support |
(×3) HDMI 2.1 with HDCP 1.4 and HDCP 2.3 support |
(×3) HDMI 2.1 with HDCP 1.4 and HDCP 2.3 support |
| Display Port 1.2 | ||||
| VGA video | ||||
| Stereo 3.5 mm (variable) | ||||
| RS-232 (DB-9 connector) | ||||
| RJ45 (LAN IN) | ||||
| USB Type‑C |
(×2) Front: 15 W power delivery |
(×2) Front: 15 W power delivery; Side: 65 W power delivery |
65 W power delivery (×2) 65 W power delivery |
(×3) Front and side: 65 W power delivery; Top: 15 W power delivery |
| USB 2.0 Type-A | ||||
| USB 3.2 Gen 1 Type‑A | (×4) | (×4) | (×3) | (×3) |
| USB 2.0 Type-B | (×2) | |||
| USB 3.2 Gen 1 Type‑B | (×4) | (×3) | (×4) | |
| Outputs | GX (V3) series | MX (V4) Pro series | 6000S (V3) Pro series | QX Pro series |
| HDMI |
HDMI 2.0 with HDCP 1.4 and 2.2 support |
HDMI 2.1 with HDCP 2.3 support |
HDMI 2.1 with HDCP 2.3 support |
HDMI 2.1 with HDCP 1.4 and 2.3 support |
| Stereo 3.5 mm (variable) | ||||
| S/PDIF optical (fixed) | ||||
| RJ45 (LAN OUT) | ||||
| OPS accessory slot | GX (V3) series | MX (V4) Pro series | 6000S (V3) Pro series | QX Pro series |
| OPS support | SMART PCM or AMG1 | SMART PCM or AM60 | SMART PCM or AM60 | SMART PCM or AM60 |
| OPS power delivery | 90 W | 60 W | 60 W | 100 W |
| Installation | GX (V3) series | MX (V4) Pro series | 6000S (V3) Pro series | QX Pro series |
| VESA mounting points | ||||
| Wall mount bracket | Optional | Optional | Included | Included |
| Included cables and accessories | Pens (×2) Remote control Country-specific power cable USB Type-A to Type-B cable |
Pens (×2) Remote control Country-specific power cable USB Type-A to Type-B cable |
Pens (×2) Erasers (×2) Remote control Country-specific power cable USB Type-A to Type-B cable |
Pens (×2) Erasers (×2) Remote control Country-specific power cable USB Type-A to Type-B cable USB Type-C cable |
| Certification and compliance | GX (V3) series | MX (V4) Pro series | 6000S (V3) Pro series | QX Pro series |
| US / Canada | cULus | FCC | ISED | TSCA | CONEG Packaging | Proposition 65 | UL | FCC | ISED | TSCA | CONEG Packaging | Proposition 65 | UL | FCC | ISED | TSCA | CONEG Packaging | Proposition 65 | UL | FCC | ISED | TSCA | CONEG Packaging | Proposition 65 |
| EU / EEA / EFTA / UK | CE | UKCA | LVD | CB | EMCD | RED | REACH | RoHS | Battery | WEEE | Packaging | POP | Ecodesign | CE | UKCA | LVD | CB | EMCD | RED | REACH | RoHS | Battery | WEEE | Packaging | POP | Ecodesign | CE | UKCA | LVD | CB | EMCD | RED | REACH | RoHS | Battery | WEEE | Packaging | POP | Ecodesign | CE | UKCA | LVD | CB | EMCD | RED | REACH | RoHS | Battery | WEEE | Packaging | POP | Ecodesign |
| Australia / New Zealand | RCM | RCM | RCM | RCM |
| Performance standards | ENERGY STAR® | HDMI | HDCP | ENERGY STAR | HDMI | HDCP | ENERGY STAR | HDMI | HDCP | ENERGY STAR | HDMI | HDCP |
| Product availability may vary by region. | This product has received additional certifications not listed here. | ||||
| Warranty | GX (V3) series | MX (V4) Pro series | 6000S (V3) Pro series | QX Pro series |
| SMART Warranty | Included. See warranty page for details. | Included. See warranty page for details. | Included. See warranty page for details. | Included. See warranty page for details. |
