Vergelijk SMART Board Displays voor het onderwijs
Download a printer-friendly PDF version of this table
Models and specifications may vary by region. Please contact your local representative for details.
 |
 |
 |
|---|
| Software | GX series | MX series | 6000S series |
|---|---|---|---|
| SMART Notebook® | Included | Included | Included |
| SMART Learning Suite | Optional | Optional | Optional |
| SMART Ink® and SMART Product Drivers | Included | Included | Included |
| Embedded features |
Digital whiteboard Web browser Screen sharing Input select File manager Overlay Interactive widgets App library Google Drive™ and OneDrive™ access |
SMART Whiteboard Native and app-based screen sharing Web browser Personalized home screen and settings Live input preview Interactive widgets Templates, graphic organizers, and manipulatives File and app libraries Google Drive and OneDrive access |
SMART Whiteboard Native and app-based screen sharing Web browser Personalized home screen and settings Live input preview Interactive widgets Templates, graphic organizers, and manipulatives File and app libraries Google Drive and OneDrive access |
| SMART OPS PC module for Windows® Pro computing | Optional | Optional | Optional |
| SMART Remote Management | Optional | Subscription for the length of the warranty | Subscription for the length of the warranty |
| Display | GX series | MX series | 6000S series |
| Screen sizes (diagonal) | 65", 75", 86" | 55", 65", 75", 86" | 65", 75", 86" |
| Resolution | 4K UHD (3840 × 2160) | 4K UHD (3840 × 2160) | 4K UHD (3840 × 2160) |
| Refresh rate | 60 Hz | 60 Hz | 60 Hz |
| Lifespan | ≥ 50,000 hours | ≥ 50,000 hours | ≥ 50,000 hours |
| LCD quality | Grade A | Grade A | Grade A |
| Brightness (maximum) | ≥ 400 cd/m² |
55": ≥ 300 cd/m² 65", 75", 86": ≥ 400 cd/m² |
≥ 350 cd/m² |
| Display response time | ≤ 8 ms | ≤ 8 ms | ≤ 8 ms |
| Glass | Fully heat-tempered, bonded, anti-glare |
55": Fully heat-tempered, anti-glare 65", 75", 86": Fully heat-tempered, bonded, anti-glare |
Fully heat-tempered, anti-glare, resists smudges and fingerprints |
| Sensors | Ambient light, infrared | Ambient light, infrared | Proximity, ambient light, infrared, room temperature, humidity |
| Speakers | 2 integrated 20 W speakers |
55": 2 integrated 15 W speakers 65", 75", 86": 2 integrated 20 W speakers |
2 integrated 20 W speakers |
| Microphone | N/A | Integrated linear six-microphone array with support for onboard acoustic echo cancellation | Integrated linear four-microphone array with support for onboard acoustic echo cancellation |
| Remote control | |||
| NFC sign in to a SMART account | |||
| Touch and interaction | GX series | MX series | 6000S series |
| Touch technology | Advanced infrared | HyPr Touch™ with Advanced IR | HyPr Touch with InGlass™ |
| Frame rate | ≥ 125 Hz | ≥ 200 Hz | ≥ 150 Hz |
| Touch response time | ≤ 8 ms | ≤ 5 ms | ≤ 9 ms |
| Accuracy | 1 mm | 1 mm | 1 mm |
| Minimum object size | 2 mm | 2 mm | 2 mm |
| Continuous touch points (fully differentiated) | Up to 20 touch points (OS dependent) | Up to 20 touch points (OS dependent) | Up to 40 touch points (OS dependent) |
| Interaction types | Pens, touch, gesture, palm erase | Pens, touch, gesture, palm erase | Pens, touch, gesture, erase, fine erase, highlighter, Tool Explorer™ tools |
| Eraser, pen, and touch differentiation (simultaneous tool differentiation) | 1 | ||
| Continuous pen, touch, and erase (continuously write, move, and gesture and erase simultaneously) | 1 | ||
| Eraser types | Palm erase | Palm erase | Palm erase, fine erase, eraser blocks |
| Azimuth erasing | Not supported | Not supported | Eraser blocks |
| Palm rejection | Non-writing hand in Android™ whiteboard | Not supported | Writing and non-writing hand |
| Object recognition | 2 | ||
| Pressure-sensitive ink | |||
| Automatic pen color recognition | |||
| Unique Pen IDs | 2: Windows and macOS, when using a finger to write or draw | 2: Windows and macOS, when using a finger to write or draw | Unlimited (available: 6 pens and dual‑color highlighter) |
| Tools included | Pens (×2) | Pens (×2) |
Pens with unique IDs and fine erasers (×2) Erasers (×2) |
| Pen type | Battery-less pen | Battery-less pen | Battery-less pen with fine eraser |
| Pen (and eraser) holders | Magnetic, frame‑mounted | Magnetic, frame‑mounted | Intelligent, magnetic, frame‑mounted |
| Additional pen colors (sold separately) | N/A | N/A |
4 color pen set: blue, green, purple, and orange (with holder) Dual-color highlighter Magic Pen |
| Additional Tool Explorer tools (sold separately) | When connected to a PC or Mac with SMART Product Drivers installed | N/A |
Early learning cube set Math cube set Play stamp set |
|
1 A connected computer with SMART Product Drivers installed is required. Only supported in SMART Notebook and SMART Ink. 2 When connected to a computer with SMART Product Drivers installed |
|||
| Embedded Android experience | GX series | MX series | 6000S series |
| Operating system | Android version 11.0 | Android version 11.0 | Android version 11.0 |
| Memory | 4 GB DDR4 | 8 GB DDR | 6 GB DDR |
| Storage | 32 GB | 32 GB (up to 544 GB) | 32 GB (up to 544 GB) |
| Updates | Over-the-air (OTA) | Automatic OTA | Automatic OTA |
| Network connectivity | GX series | MX series | 6000S series |
| Wired | RJ45 (×2) 1000BASE-T | RJ45 (×2) 1000BASE-T | RJ45 (×2) 1000BASE-T |
| Wi-Fi | IEEE 802.11ax (Wi-Fi 6) supporting WEP, WPA, WPA2 PSK, and 802.1X EAP authentication protocols | IEEE 802.11ax (Wi-Fi 6) supporting WEP, WPA, WPA2, PSK, WPA3, and 802.1X EAP authentication protocols | IEEE 802.1ac (Wi-Fi 5) supporting WEP, WPA, WPA2, PSK, and 802.1X EAP authentication protocols |
| Bluetooth | 5.0 dual mode | 5.2 dual mode | 5.0 dual mode |
| Radio and Bluetooth restrictions? Learn more | |||
| Classroom connectivity | GX series | MX series | 6000S series |
| Number of student devices connected to the display | 9 | 40+ through any web browser, no sign in required3 | 40+ through any web browser, no sign in required3 |
| Whiteboard broadcast | N/A |
200 (unlimited)3 Live content and annotation updates |
200 (unlimited)3 Live content and annotation updates |
| Student device collaboration activities | |||
| Whole-class collaboration tools | N/A |
Two-way annotation: ink and text tool to whiteboard canvas with student attribution Polling and voting Checks for understanding Questioning and reflection exercises Freeform or categorized brainstorming and ideation Activating prior knowledge exercises |
Two-way annotation: ink and text tool to whiteboard canvas with student attribution Polling and voting Checks for understanding Questioning and reflection exercises Freeform or categorized brainstorming and ideation Activating prior knowledge exercises |
| Device connection options (screencast) |
|
|
|
| Device connection options (whiteboard) | N/A |
Live whiteboard broadcast through any web browser Contribution access through any web browser, including collaboration activities |
Live whiteboard broadcast through any web browser Contribution access through any web browser, including collaboration activities |
| Teacher control options (screencast) | Moderated with 9× grid view |
Unmoderated Moderated with 4× grid view |
Unmoderated Moderated with 4× grid view |
| Teacher control options (whiteboard) | N/A |
Teacher-led navigation Student-paced navigation Pause contributions to collaborative whiteboard canvas |
Teacher-led navigation Student-paced navigation Pause contributions to collaborative whiteboard canvas |
| Video conferencing platform interoperability (Zoom™, Microsoft Teams™, Google Meet™, Webex®, and more) |
Supports any platform on any connected computer Administrator installation through SMART Remote Management (sold separately) |
Supports any platform on any connected computer Add popular Android apps through iQ app store Administrator installation through SMART Remote Management (included) |
Supports any platform on any connected computer Add popular Android apps through iQ app store Administrator installation through SMART Remote Management (included) |
| 3 Unlimited connections available to whiteboard. Speed and function subject to individual network capabilities. | |||
| Inputs/outputs | GX series | MX series | 6000S series |
| Convenience buttons | Power, home, freeze frame, volume | Home, power, volume, input select, screen shade, freeze frame | Power, home, volume, screen shade, freeze frame |
| Inputs | HDMI® 2.0 ×3 (HDCP 1.4 and 2.2), Display Port, VGA, stereo 3.5 mm, RS‑232, RJ45, USB‑C ×2, USB‑A 3.2 ×4, USB‑B 2.0 ×2, USB‑A 2.0 | MicroSD slot, HDMI 2.1 ×3 (HDCP 1.4 and 2.3), RS‑232, RJ45, USB‑C ×2, USB‑A 2.0, USB‑A 3.2 ×4, USB‑B 3.2 ×3 | HDMI 2.1 ×3 (HDCP 1.4 and 2.3), VGA, stereo 3.5 mm, RS‑232, RJ45 ×2, USB‑A 2.0, USB‑B 2.0, USB‑A 3.0 ×3, USB‑B 3.0 ×3, USB‑C ×2 |
| Outputs | HDMI 2.0 (HDCP 1.4 and 2.2), RJ45, S/PDIF, stereo 3.5 mm | Stereo 3.5 mm, S/PDIF, RS-232 | HDMI 2.1 (HDCP 2.3), stereo 3.5 mm, S/PDIF |
| OPS support | |||
| Installation | GX series | MX series | 6000S series |
| VESA mounting points | |||
| Mini-VESA mount point for NUC | |||
| Wall mount bracket | Optional | Optional | Included |
| Certification and compliance | GX series | MX series | 6000S series |
| US/Canada | FCC, ISED, TSCA, CONEG Packaging, Proposition 65 | FCC, ISED, TSCA, CONEG Packaging, Proposition 65 | FCC, ISED, TSCA, CONEG Packaging, Proposition 65 |
| EU/EEA/EFTA/UK | CE, UKCA, LVD, CB, EMCD, RED, REACH, RoHS, Battery, WEEE, Packaging, POP, Ecodesign | CE, UKCA, LVD, CB, EMCD, RED, REACH, RoHS, Battery, WEEE, Packaging, POP, Ecodesign | CE, UKCA, LVD, CB, EMCD, RED, REACH, RoHS, Battery, WEEE, Packaging, POP, Ecodesign |
| Australia/New Zealand | RCM | RCM | RCM |
| Performance standards | ENERGY STAR® , HDMI, HDCP | ENERGY STAR, HDMI, HDCP | ENERGY STAR, HDMI, HDCP |
| Product availability may vary by region. | These products have received additional certifications not listed here. | |||
| Warranty | GX series | MX series | 6000S series |
| SMART Assure or limited equipment warranty | Included. See warranty page for details. | Included. See warranty page for details. | Included. See warranty page for details. |
