Compare SMART Board Pro Displays for Business
Models and specifications may vary by region. Please contact your local representative for details.
 |
 |
 |
 |
|---|
| Display | SMART Board® Mini | T Pro series | MX Pro series (V5) | QX Pro series (V2) |
|---|---|---|---|---|
| Screen sizes (diagonal) | 27" | 65" | 75" | 86" | 55" | 65" | 75" | 86" | 65" | 75" | 86" |
| Display type | LCD | QLED | Dolby Vision support | LCD | LCD |
| Resolution | 4K UHD (3840 x 2160) | 4K QLED (3840 x 2160) Dolby Vision support |
4K UHD (3840 x 2160) | 4K UHD (3840 x 2160) |
| Refresh rate | 60 Hz | 60 Hz | 60 Hz | 60 Hz |
| Lifespan | ≥ 50,000 hours | ≥ 50,000 hours | ≥ 50,000 hours | |
| LCD quality | Grade A | Grade A | Grade A | Grade A |
| Brightness1 | 500 cd/m² | 850 cd/m² | 55": 300 cd/m² 65", 75", 86": 400 cd/m² |
490 cd/m² |
| Display response time | ≤ 14 ms | ≤ 8 ms | ≤ 8 ms | ≤ 8 ms |
| Glass | Optically bonded | Anti-glare | Anti-fingerprint | Full heat-tempered | Anti-glare | Bonded | 55": Full heat-tempered | Anti-glare 65", 75", 86": Full heat-tempered | Anti-glare | Bonded | Optically bonded | Anti-glare | Anti-fingerprint | Heat-tempered |
| Sensors | Ambient light | Ambient light | Infrared | Proximity2 | Ambient light | Infrared | Proximity | Ambient light | Infrared | Room temperature | Humidity | Volatile organic compound (VOC) | Particulate Matter (PM2.5)3 |
| Speakers | 12W (2x 6W speakers) | 60W (2x 20W speakers, 1x 20W subwoofer) | 55": 30W (2x 15W speakers) 65", 75", 86": 40W (2x 20W speakers) |
55W Integrated soundbar (2x 20W speakers, 1x 15W subwoofer) |
| Microphone | Integrated eight-microphone array with built-in acoustic echo cancellation | Integrated eight-microphone array with built-in acoustic echo cancellation | Integrated six-microphone array with built-in acoustic echo cancellation | Integrated eight-microphone array with visual mute status indicator and built-in acoustic echo cancellation |
| QR code sign in to a SMART Account | ||||
| NFC sign in to a SMART Account | ||||
| SMART 4K UHD Camera | Included Integrated privacy shutter Removable |
Optional | Optional | Included (SWC120UHD) Privacy cover Removable |
| Convenience buttons | Privacy screen | Input select | Settings | Volume | Microphone mute | Ink color | Power | Volume | Input select | Power | Home | Volume | Input select | Screen shade | Freeze frame | Power | Home | Volume | Microphone mute | Freeze frame |
|
1Brightness of individual displays can vary. 2Only available on some models 3The display’s environmental sensors are not life safety rated sensors: they provide general information only. |
||||
| Touch and interaction | SMART Board® Mini | T Pro series | MX Pro series (V5) | QX Pro series (V2) |
| Touch technology | PCAP | HyPr Touch with Advanced IR | HyPr Touch™ with Advanced IR | HyPr Touch with Advanced IR |
| Frame rate | ≥ 300 Hz | ≥ 200 Hz | ≥ 300 Hz | |
| Touch response time | ≤ 3.3 ms | ≤ 5 ms | ≤ 4 ms | |
| Accuracy | < 1 mm | 1 mm | 1 mm | |
| Minimum object size | ≤ 1.5 ms | ≤ 1.5 ms | 2 mm | 2 mm |
| Continuous touch points (fully differentiated) | Up to 10 touch points (OS dependent) | Up to 50 touch points (OS dependent) | Up to 50 touch points (OS dependent) | Up to 50 touch points (OS dependent) |
| Interaction types | Stylus | Touch | Gesture | Pens | Touch | Gesture | Palm erase | Pens | Touch | Gesture | Palm erase | Pens | Touch | Gesture | Erase | Fine erase | Tool Explorer tools |
| Eraser, pen, and touch differentiation (simultaneous tool differentiation) | Enhanced size differentiation (Pen tip, pen tail, finger, and fist) |
|||
| Continuous pen, touch, and erase (continuously write, move, and gesture and erase simultaneously) | ||||
| Eraser types | Back-end of stylus | Palm erase | Back of pen | Palm erase | Palm erase | Fine erase | Eraser blocks |
| Azimuth erasing | Eraser blocks | |||
| Palm rejection | Writing and non-writing hand |
|||
| Object recognition | ||||
| Pressure-sensitive ink | (4096 points of pressure) |
(4096 points of pressure) |
||
| Automatic pen color recognition | ||||
| Support for multi-function pens | ||||
| Unique Pen ID support | 1 | 4 | 2: Windows and macOS, when using a finger to write or draw | Unlimited |
| Tools included | Stylus (x1) | Pens (x2) | Pens (x2) | Pens with unique IDs and fine erasers (x2) Erasers with angle of orientation (x2) |
| Tool holders | Magnetic | In-bezel stylus charger | Frame side-mounts | Magnetic | Frame‑mounted | Magnetic | Frame‑mounted | Intelligent | Magnetic | Frame‑mounted |
|
4A connected computer with SMART Product Drivers installed is required. Only supported in SMART Notebook® and SMART Ink. 5When connected to a computer with SMART Product Drivers installed |
||||
| Embedded OS | SMART Board® Mini | T Pro series | MX Pro series (V5) | QX Pro series (V2) |
| Operating system | No embedded compute | No embedded compute | Android version 13 (Update to Android version 15 available end of 2025) |
Android version 13 (Update to Android version 15 available end of 2025) |
| CPU | Octa-core | Octa-core | ||
| Memory | 8 GB DDR4 | 8 GB DDR4 | ||
| OS architecture | 64-bit | 64-bit | ||
| Storage | 64 GB (up to 576 GB) | 64 GB (up to 576 GB) | ||
| Updates | OTA system | Automatic OTA, system and Software | Automatic OTA, system and Software | |
| Network connectivity | SMART Board® Mini | T Pro series | MX Pro series (V5) | QX Pro series (V2) |
| Wired | RJ45 (x1) 1000BASE-T | pass-through | RJ45 (x2) 1000BASE-T | pass-through | RJ45 (x2) 1000BASE-T | RJ45 (x2) 1000BASE-T | pass-through |
| Wi-Fi | IEEE 802.11ax (Wi-Fi 6e) Wi-Fi hotspot |
IEEE 802.11ax (Wi-Fi 6) Wi-Fi hotspot |
||
| Bluetooth® | 5.2 dual mode | 5.2 dual mode | ||
| Inputs | SMART Board® Mini | T Pro series | MX Pro series (V5) | QX Pro series (V2) |
| OPS PC accessory slot | ||||
| microSD slot | ||||
| HDMI® | x1 HDMI 2.1 |
(x3 HDMI 2.1, with ARC/eARC) |
(x4) (x4 HDMI 2.1, with ARC/eARC on HDMI2) |
(x3) (x3 HDMI 2.1, with ARC/eARC on HDMI2) |
| VGA video | ||||
| Stereo 3.5 mm (variable) | ||||
| RS-232 (DB-9 connector) | ||||
| RJ45 (LAN IN) | ||||
| USB Type-C | (x1 supporting 4K, touch, peripherals and 65W power) |
(x2 supporting 4K, touch, peripherals and 100W front power) |
(x2 supporting 4K, touch, peripherals and 27W front power; 65W side power) |
(x3 Front and side supporting 4K, touch, peripherals and 65W power; Top: supporting peripherals and 15W power) |
| USB Type-A | (x2 USB 3.0) |
(x1 USB 2.0) |
(x1 USB 2.0) |
|
| USB Gen 1 TypeA | (x4 USB 3.2) |
(x2 USB 3.2) |
(x3) |
|
| USB Type-B | (x1 USB 3.0) |
(x2 USB 3.0) |
||
| USB Gen 1 TypeB | (x4 USB 3.2) |
(x4) |
||
| Outputs | SMART Board® Mini | T Pro series | MX Pro series (V5) | QX Pro series (V2) |
| HDMI | (x1 HDMI 2.1) |
(x1 HDMI 2.1) |
(x1 HDMI 2.1) |
(x1 HDMI 2.1) |
| USB Type‑C | (x1 supporting 4K and touch) |
(x1 supporting 4K, touch and 4.5W power) |
(x1 supporting 4K, touch and 4.5W power) |
|
| Stereo 3.5 mm (variable) | ||||
| S/PDIF optical (fixed) | ||||
| RJ45 (LAN OUT) | ||||
| OPS accessory slot | SMART Board® Mini | T Pro series | MX Pro series (V5) | QX Pro series (V2) |
| OPS support | SMART PCM | SMART AM60 | SMART Chromebox | SMART PCM | SMART AM60 | SMART Chromebox | SMART PCM | SMART Chromebox | SMART PCM | SMART Chromebox |
| OPS power delivery | 65W | 90w | 85W | 100W |
| Installation | SMART Board® Mini | T Pro series | MX Pro series (V5) | QX Pro series (V2) |
| VESA mounting points | ||||
| Wall mount bracket | Optional | Optional | Optional | |
| Included cables and accessories | Country-specific power cable Remote control Stylus with fine eraser and tether Replacement stylus nibs 4K camera 10' (3 m) USB Type-A to Type-B cable 6' (1.8 m) USB Type-C cable |
Country-specific power cable Remote control Pens (×2) 16' 5" (5 m) USB Type-A to Type-B cable 6' (1.8 m) USB Type-C cable |
Country-specific power cable Remote control Pens (×2) 16' 5" (5 m) USB Type-A to Type-B cable 6' (1.8 m) USB Type-C cable |
Country-specific power cable Remote control Pens (×2) Erasers (×2) 16' 5" (5 m) USB Type-A to Type-B cable 6' (1.8 m) USB Type-C cable |
| Software | SMART Board® Mini | T Pro series | MX Pro series (V5) | QX Pro series (V2) |
| SMART Meeting Pro® Room license | Optional (included with PCM OPS module bundles) | Included | Included | Included |
| SMART Meeting Pro Personal license (x10) | Optional | Included | Included | Included |
| SMART TeamWorks™ Room license | Optional | Optional | Optional | Optional |
| SMART OneLaunch license | Optional | 1-year subscription included | ||
| SMART Product Drivers and SMART Ink® | Included | Included | Included | Included |
| SMART Remote Management | Subscription for the length of the warranty | Subscription for the length of the warranty | ||
| Embedded features | Input select | Input select | Digital whiteboard Chrome™ browser Wireless screen sharing Google Play™ store Personalized home screen and settings Input select Split screen PIP with touch pass-through Templates File and app libraries Google Drive™ and OneDrive™ access |
Digital whiteboard Chrome browser Screen sharing Google Play store Personalized home screen and settings Input select Split screen PIP with touch pass-through Templates File and app libraries Environmental sensors dashboard Tool Explorer Image Editor Google Drive and OneDrive access |
| Certification and compliance | SMART Board® Mini | T Pro series | MX Pro series (V5) | QX Pro series (V2) |
| US / Canada | cULus | FCC | ISED | TSCA | CONEG Packaging | Proposition 65 | UL | FCC | ISED | TSCA | CONEG Packaging | Proposition 65 | UL | FCC | ISED | TSCA | CONEG Packaging | Proposition 65 | UL | FCC | ISED | TSCA | CONEG Packaging | Proposition 65 |
| EU / EEA / EFTA / UK | CE | LVD | CB | EMCD | REACH | RoHS | Battery | WEEE | Packaging | POP | Ecodesign | CE | UKCA | LVD | CB | EMCD | REACH | RoHS | Battery | WEEE | Packaging | POP | Ecodesign | CE | UKCA | LVD | CB | EMCD | RED | REACH | RoHS | Battery | WEEE | Packaging | POP | Ecodesign | CE | UKCA | LVD | CB | EMCD | RED | REACH | RoHS | Battery | WEEE | Packaging | POP | Ecodesign |
| Australia / New Zealand | RCM | RCM | RCM | RCM |
| Performance standards | ENERGY STAR® | HDMI | HDCP | DOLBY VISION® | ENERGY STAR | HDMI | HDCP | HDR10 | HLG | ENERGY STAR | HDMI | HDCP | ENERGY STAR | HDMI | HDCP |
| Product availability may vary by region. | This product has received additional certifications not listed here. | ||||
| Warranty | SMART Board® Mini | T Pro series | MX Pro series (V5) | QX Pro series (V2) |
| SMART Warranty | Included. See warranty page for details. | Included. See warranty page for details. | Included. See warranty page for details. | Included. See warranty page for details. |
